She’s on 18” wheels here wrapped wing mirrors, dechromed window trims


Sent from my iPhone using Tapatalk

Hi,
i buy one front radar sensor for my Insignia to implement it for AAC.
Part number of sensor module are 23438076. About cabling that i found is:
pin-1 - 12v Positive voltage - DRAW CURRENT - 900mA
pin-2 - GND Negative voltage
pin-5 - Circuit 6106 - White                   connected to pin-20-ABS
pin-6 - Circuit 6105 - BU/YE                  connected to pin-21-ABS
pin-7 - Circuit 2501 - WH - CAN L          connected to pin-6-ABS
pin-8 - Circuit 2500 - BU - CAN H          connected to pin-5-ABS
pin-10 - Circuit 5986 - WH/BU - IGN      connected to pin-33-ABS    -  +12DC / 3mA

The question is 12v Positive are is ALL time or switched?
Circuit 6106 is ??
Circuit 6105 is ??

Receptacle connector is 1488533-5 or 2203663-5. The first one is out of make.
I have a opel-eye in my car, have all needed buttons on steering wheel only this radar is missing and activation too

I attach specification for this sensor but cabling are for Range Rover.
The second file are connector. For this sensor fit Option A Black with 2 Notches in two ends.


Regards

Attached Files

  radar sensor.pdf (Size: 321.25 KB / Downloads: 29)
  ENG_CD_2203663_A7.pdf (Size: 687.56 KB / Downloads: 25)

Being working on this little retrofit for awhile now gathering the parts.

So I have the following parts.

Front shock's with springs, rear shocks, Front and rear sensors & the Flexride module.

I found it really hard to find the correct plug needed for the front strut extension harness, the only place that "stocked it" never had any stock and kept saying stock was coming in for months until I got shitty with them then they cancelled the order and refunded me.

I was able to finally find the plugs on ebay a little expensive as I had to buy the extension harness with them.

I did buy all the wire to make the loom myself but @Vocky had a loom which he sent me which meant I only needed to change the wire out to the engine bay.

The module both front and rear sensors are fitted & I've fitted the loom out to the engine bay so far.

I've made the 2 looms which run to the front sensors & my next looms to make is the 2 looms to the front shocks but I am awaiting some wire to arrive as I need to add the front wheel speed sensor wiring into them.

Then I plan on some ramp time to swap the shocks over.

Shocks and module


Flex ride main loom







Module fitted behind the Rear fuse-board





The 2 small looms for the front sensors made.



This retrofit also involves the fitment of EPB so here is the EPB loom made which has been fitted.

hi i have fitted a navi 650 and bluetooth unit but the problem is that the steering wheel controls are not right .. also its not showing the dab ....what have i done wrong as i fitted one before with no problems at all....help please

Hi all,
Does anyone know how I can get my hands on the front spoiler and side skirts in the image below? Thanks:




Sent from my iPhone using Tapatalk

Hi folks

Full leather VXR seats for sale on ebay for a bargain price of £1494.99 or make offer.

https://www.ebay.co.uk/itm/Astra-J-VXR-G...%7Ciid%3A1

So my friend cooked his gtc 1.6 turbo and ive just stripped it got head skimmed and rebuilt with new gaskets.

The engine starts but soon after it starts to run a bit lumpy. I can rev is but hear a slight miss.

Now i am not sure why this air hole is in the rocker cover but i can clearly hear it sucking air in. And if i put my finger over it it sucks it in.
Can u tell me if this is normal please?.

I have included a picture of the vent and a video for reference. If u have any clues as to maybe i have some one way valve blocked from the mayo deposits from the hgf maybe?
I am not sure if the air and rough idle are related but any help is appreciated.
Ideas please. Thanks. T

Video link to onedrive..
https://1drv.ms/v/s!ApJp1ozW22j-xB-5GuwVxfvOLhfT

Sent from my SM-G960F using Tapatalk

When driving last night i got the "electronic stability control & traction system" symbol when is staying constant.

Today it appeared again AND a flashing "malfunction indicator light" also appeared. The cars power was restricted.

Its a 2012 1.4 petrol. The car is misfiring a small bit.

Can anyone advise the problem?

Hi all,

I'm a recent owner of a 2016 GTC 1.6T LE - in red. Love the car and have been a Vx fan for years, having worked my way up from a Manta, through Carltons, Cavaliers and Omegas, and a Zafira at one point up to this GTC. I've had a couple of older GTCs in the past and haven't found much else comes close for the price!

I love the look of them, and the LE is well equipped, not keen on the fuel economy or the price of the 20" tyres, but I knew this wasn't a budget shopping car! Gearchange is a bit clonky sometimes as well, but I thought the same about my older Vectra 2.0 turbo so I guess its business as usual. I know the M32 box has a terrible reputation but I've got a bit of warranty on this car!
